FINE ART 1536 LED matrix PANEL LIGHTS MOVING HEAD STAGE LIGHTING

FINE 1536 PANEL is a beam matrix moving head light fixture with unlimited rotatable X/Y. It adopts high quality OSRAM RGBW 4 in 1 LED as light source, each light source can be controlled separately. This fixture can project dynamic pictures and strong dynamic multi-directional beam in three-dimensional space, which can create very bright light effects
Light source
Osram 15w 4 in 1 LED lamp beads
Average life span≥ 50,000 h

OPTICAL SYSTEM
Beam angle 8°，PMMA high-quality optical lens
Power supply: 600W
Light efficiency:23 lm/w
Luminous flux: ＞14000 lm

COLOR SYSTEM
4 colors, 4 colors overlay for white, matrix control 36 pcs RGBW 4 in 1 LEDs, unlimited rotation and narrow beam can create unlimited dynamic effect and color change

EFFECTS
All-optical domain dimming, 65536 grade dimmer accuracy
High light output, low glare
Fast strobe: 1-25HZ
Color macro and color gradually changed

X/Y movement angle
Pan unlimited，Tilt unlimited

CONTROL AND PROGRAMMING
Control channel: 19/130/167 control channel model
Protocol: Standard DMX512 protocol Artnet, wireless DMX for option
Menu display: LED display
DMX signal connection: 3 or 5-pin XLR input/output

BODY
Aluminum structure with die-cast plastic cover
Two handles for transportation

ELECTRIC CONTROL TECHNOLOGY
Fixture reset is controlled through menu or light console
0-100% dimmer
Constant current drive mode
Temperature sensing, intelligently adjust light source power
DMX channel level monitoring
Fixture information query
Intelligently fan speed adjustment
Set the initial brightness of all kinds of colors

POWER SUPPLY
AC90-250V   50/60Hz
Switch power

INPUT POWER
550W,PFC≥0.95

SAFETY PROTECTION
Overcurrent , overvoltage and overheating protection

WORKING POSITION
Any safety position to install

WORKING TEMPERATURE
﹣10℃-45℃

IP RATE
IP20

DIMENSION
Fixture dimension: 483×550×282mm。

WEIGHT
N.W: 20kg

PACKAGE
2pcs/ flight case

Certificates of Honor from 2nd Summer Youth Olympic Games Organizing Committee（fine art lighting moving head also take part in the Games)

The 2nd Summer Youth Olympic Games was held successfully in Nanjing China this August. To thank the participation and contribution of involved parties, the 2nd Summer Youth Olympic Games Organizing Committee issued the certificates of Honor for Guangzhou Chaiyi Light Co., Ltd and its general manager Mr. Jianhua Liu.

FINE ART Lighting Shines at the 5th Hong Kong Asian-Pop Music Festival 2015

The 5th Hong Kong Asian-Pop Music Festival 2015(HKAMF
2015), organized by the International Federation of
the Phonographic Industry (Hong Kong Group) Limited
and supported by Hong Kong Trade Development Council
(HKTDC) was held at the Hong Kong Convention &
Exhibition Centre (HKCEC) Hall 5BC on 27th March
2015.
Keeping the same theme of “Music In One Asia", the
5th Hong Kong Asian-Pop Music Festival 2015(HKAMF
2015) continued its tradition of bringing together
top pop performers and budding recording artistes
from Asian countries such as China, Taiwan, Japan,
Korea, Singapore, Malaysia and Thailand and the host
city Hong Kong.
Fine Art provided more than 200 units of its lighting
fixtures for this grand festival. 63 units of the
Fine 2500 spot, 56 units of the Fine 2500 wash and
100 units of Fine X-treme 230Enha illuminated the
stage, creating a dazzling backdrop and atmosphere
for all the performers.
The Fine 2500 series, in particular, is a mature
product range known for its stable performance and
excellent function. Featuring infinite linear CMY and
CTO colour temperature adjustment, the FINE 2500 wash
created vibrant and colorful stage effects that met
the festival’ s diverse lighting needs. At the same
time, the FINE 2500 spot provided the HKAMF audience
with fantastic visual lighting effects with its
three-facet prism, beam shaper prism and frost lens.
This series has been used in many famous events such
as the 16th  Asian Games Opening Ceremony in
Guangzhou, the 2014 Nanjing Youth Olympic Games, and
the 2014 Beijing APEC summit.

GUANGZHOU CAIYI LIGHT CO.,LTD
http://en.fineart-light.com/
marketing@fineart-light.com
stage lighting manufacture

800w follow spot light stage lighting equipments in China hot sale!

FINE 800SF
Lamp Source: MSD Platinum 800W reflective bowl
Life Span: 1000h
Overall Output of Luminous Flux: 15675lm
Light Efficiency: 16.23 lm/W
Evenness: 91%
Focus：6-16°
Function Equipment:
1 set color changer(5 color paper clips)
1 facula control iris
1 set liner dimmer equipment
1 pair  bilateral cutting disk
1 CTO
1 frost effect
Power
AC 100-240V/50/60Hz

Fine Art 2000w moving head wash light moving light

FINE 2000 WASH-PERF is a kind of moving head with
image cutting system and wash function. It uses a
1200w double-end short-arc discharge lamp and is
equipped with a linear smooth CMY color mix system
and CTO color temperature correction, 8 alterable
color filter, 1 set of linear uniform, soft beam
expander which makes FINE 2000 WASH-PERF work as a
beam light when the soft beam expander fully opens.
With high brightness output and iris adjustment, this
fixture can fully show the air beam effect. Besides,
it can show the strong light and the charming colors
on the stage by the image cutting system and wash
function.

● 1200W double-ended short-arc discharge lamp
● CMY color mixing system + linear CTO(6500K-2800K)
● 2 fixed color wheels with 8 color filters
● 1 set soft light expander, Angle range: 9°-35°
● 0-100% mechanical dimming + fast strobe(1-10
times/sec)
● Pan 540°,Tilt 270 °,8 bit or 16 bit resolution
● LCD display menu, English and Chinese language
option
● With high-performance electronic hardware and
mature humanized software control system, the fixture
is stable and reliable.
● Modular structure design, simple, fast and
convenient maintenance
Lamp Source
Lamp: 1200W double-ended short-arc discharge lamp
Model: OSRAM HTI 1200W/D7/60 or PHILIP MSR GOLDTM
1200 SA/DE
Lamp Cap: SFc10-4
Color temperature: 6000K
Luminous flux: 1100001m
Rated life: 750 hours

Optical System
Imported European Microcrystalline trellis cold glass
reflector, 3 groups of high definition lenses
Electronic linear zoom for beam angle 9°-35°

Color System
2 fixed color wheels with 8 color filters+ white
（color filters in one of the color wheels can be
replaced by gobos） , CMY linear color mixing+ CTO
color temperature linear correction

Effect Section
Dimmer and strobe device, 0-100% linear dimmer,
strobe speed, 1-10 flash/ sec, iris can be linearly
controlled within 5-100%, macro function.

Control and Programming
Control channels: 2 control modes ,28(standard)/45
（16Bit）
DMX Protocol: DMX 512
Manu display: LCD, Chinese and English for option
Resolution control: pan, tilt
 DMX signal connection: 3 pin and 5 pin XLR
input/output

Body
Aluminum structure + die-cast plastic shell
2 handles
Pan and tilt lock for the convenience of
transportation

Movement Parameter
Angle: Pan 540°，Tilt 270°
Max Speed: pan 3.38 seconds (360°)，Tilt 2.30
seconds(270°)
Resolution: Pan=2.11°, Pan Fine=0.008°, Tilt=1.05°
,Tilt Fine=0.004°
With electro-optic reset system, pan and tilt can
automatically reposition after accidental movement.
Electronic Control Technology
Option of External battery interface, built-in self-
charge battery
Reset controlling via manual or console
Lamp on/off through remote control
Switching controlling modes
Switching Pan/Tilt speed mode
When light is off or CMY closes, power will
automatically decrease.
Electronic sensor
Input signal protection
DMX channel monitor
Lighting information inquiry
Motor zero 16bit control

Power Supply
AC200-240V 50/60Hz

Input Power
1450W, power factor PFC≥0.98

Security and Protection
Over current, over voltage and overheating protection

Working Position
Horizontal or hang

Standard Certification
GB7000.1-2007；GB7000.217-2008和GB17625.1-2003
standard

Dimension
477×409×739mm

Weight
38.8 Kg (E)/ 48.6 kg (M )

2500w led moving head light for stage lighting fixtures events

http://en.fineart-light.com/

FINE 2500 ENHA has all the function of FINE 2500 SPOT. But it has an additional function—animation effect which enables it to perform infinite and dynamic charm on the stage. It can  fully reflect the powerful effects by the followings: a professional CMY color mix system, CTO color temperature correction system, seven fixed color filters, ten rotation gobos, prism, beam  shaper, alterable frost effect, 0-100% dimmer and strobe, 5-100% alterable iris, 10-55°optical zoom, high-definition optical components, quick scan  at pan 540°，tilt 270°. Ballast option:  electronic or magnetic.

● 1500W double-ended short-arc discharge lamp
● Optical zoom 10°-55°
● CMY color mixing system + linear CTO(6500K-2800K)
● 1 fixed color wheel （7 +1）
● 2 rotating gobo wheels (5+5),10 gobos
● 1 rotating animation wheel, which can precisely position
● 1 effect wheel (1 three-facet prism+1 beam shaper prism+ 1 frost filter)
● mechanical iris (5-100%), fast movement(preset macro function)
● 0-100% mechanical dimming + fast strobe(1-10 times/sec)
● Pan 540°,Tilt 270 °,8 bit or 16 bit resolution
● LCD display menu, English and Chinese language option
● With high-performance electronic hardware and mature humanized software control system, the fixture is stable and reliable.
● Modular structure design, simple, fast and convenient maintenance

Lamp Source
Lamp: 1500W double-ended short-arc discharge lamp
Model: OSRAM HTI 1200W/D7/60 or PHILIP MSR GOLDTM 1200 SA/DE
Lamp Cap: SFc10-4
Color temperature: 6000K
Luminous flux: 165000lm
Rated life: 750 hours

Optical System
Imported European Microcrystalline trellis cold glass reflector, 3 groups of high definition lenses Electronic linear zoom for beam angle 10°-55°，focus from 2m to infinite

Color System
1 fixed color wheel with 7 color filters+ white、CMY linear color mixing、CTO color temperature linear correction

Gobo System
2 rotating gobo wheels with 5 bidirectional rotating and positioning gobos(Outer diameterΦ37.5+0/-0. 3 mm ,gobo Φ30mm)
The animation wheel, which has a precise positioning function, can simulate dynamic effects such as flow, fire, cloud, rain, etc when using with some special gobos.

Effect Section
1 effect wheel (1 three- facet prism+ 1 beam shaper prism+ 1 gradient frost filter ) ,dimmer and strobe device, 0-100% linear dimmer, strobe speed, 1-10 flash/sec,fast electric iris 5-100% linear adjustment ,macro function.

Control and Programming
Control channels: 2 control modes ,31(standard)/38（16Bit）
DMX Protocol: DMX 512
Manu display: LCD, Chinese and English for option
Resolution control: pan, tilt, gobo,  focus, dimmer 16bit
DMX signal connection: 3 pin and 5 pin XLR input/output

Body
Aluminum structure + Molded plastic shell, 2 handles, pan and tilt lock for the convenience of transportation.

Movement Parameter
Angle: Pan 540°，Tilt 270°
Max Speed: pan 3.38 seconds (360°)，Tilt 2.30 seconds(270°)
Resolution: Pan=2.11°, Pan Fine=0.008°, Tilt=1.05°,Tilt Fine=0.004°
With electro-optic reset system, pan and tilt can automatically reposition after accidental movement

Electronic Control Technology
Option of External battery interface, built-in self-charge battery
Reset controlling via manual or console
Lamp on/off through remote control
Switching controlling modes
Switching Pan/Tilt speed mode
When light is off or CMY closes, power will automatically decrease.
Electronic sensor
Input signal protection
DMX channel monitor
Lighting information inquiry
Motor zero 16bit control

Power Supply
AC200-240V 50/60Hz

Input Power
1890W, power factor PFC≥0.98

Safety Protection
Over current, over voltage and overheating protection

Working Position
Horizontal or Hang

Standard Certification
GB7000.1-2007；GB7000.217-2008 and GB17625.1-2003 standard

Dimension
477×409×798mm

Weight
40.4Kg (E)/ 52.6 kg (M )

Fine art stage lighting won the 2011 annual famous brand strategy award in Baiyun district

On May 4th, in order to cite the advanced enterprise who made outstanding contribution for the economic development, the communist part of China, Guangzhou Baiyun district and Guangzhou Baiyun government hold the 2011 annual economic recognition meeting, relying on the outstanding performance and achievements, Fine art won the 2011 annual famous brand strategy award
The meeting was presided over by deputy warden of Baiyun District Committee Zhong Xiangdong, deputy Wu Jinming read the recognition decision. In order to commend the advance, set up the typical, Baiyun district committee, district government awarded the advanced units to 15 companies who finished the task of tax revenue, 16 units including Guangzhou Wanda Square investing limited companies the outstand contribution for tax award, 48 units including Guangzhou Fuli Property limited co., LTD large taxpayer award, 25 units including Fine art advanced company of famous brand strategy award. After the award, the representative of the awarded companies delivered their acceptance speech in turn. District committee deputy clerk, warden Ma Wentian and district clerk, district people’s congress standing committee director Luo Weifeng delivered a speech respectively.
As is reported, this commendation congress took the theme of “ commend the advanced, develop economy”, when commend the advanced, the district government also hope all the companies take them as example, solidarity to optimize the environment of economic development, try our best to improve the quality and efficiency, promote economic development, social harmony and people’s happiness, strive for the development of Baiyun new glory.

Fine 1200w led moving head light

FINE 1200 WASH is a professional wash moving head .It
is equipped with a 1200W double end short arc
discharge lamp.  Linear and smooth CMY color mixing,
CTO color temperature correction. 2 color wheels with
12 color filters, option of linear and uniform soft
light expander, independent dimmer and fast strobe.
Ballast option:  electronic or magnetic.

• 1200W double end short arc discharge lamp
• CMY color mixing system + linear CTO (6500K-2800K)
• 2 fixed color wheels with 12 color filters
• 1 soft light expander, beam angle option: standard
(11°-44°), other PC lens(9°-35°)，astigmatic
lens(85°-105°)
• Independent 0-100% dimmer + fast strobe (1-13
times/sec)
• Pan 540°, Tilt 270°, 8bit or 16bit resolution
• Manu display: LCD, option of Chinese and English
• High-quality electronic hardware and mature user-
friendly software control system make the fixture
steady and reliable
• Modular structure, easy, fast and convenient for
maintenance
Lamp Source
1200W double end short arc discharge lamp
Lamp type: OSRAM HTI 1200W/D7/60或PHILIP MSR GOLDTM
1200 SA/DE
Lamp Cap: SFc10-4
Color temperature: 6000K
Luminous:  110000lm
Average life: 750 hours

Optical System
Imported European Microcrystalline trellis cold glass
reflector, 3 groups of high definition lenses
Beam angle linear electronic zoom, option:  standard
(11°-44°), PC lens(9°-35°),astigmatic lens(85°-
105°)

Color System
2 fixed color wheel with 12 colors+ open white, CMY
color mixing system, CTO color linear adjustment

Effects Configuration
Independent dimmer and strobe device, 0-100% linear
dimmer, strobe speed: 1-13 times/sec,  macro function

Control and Programming
Control channels: 3 controlling modes , 18
（(standard)/ 20（16Bit）/25 (extended)
DMX Protocol: DMX 512, ART-NET, wireless DMX
Manu display: LCD, option of Chinese and English
Resolution control: Pan, Tilt
DMX signal connection: 3 pin and 5 pin XLR
input/output

Fixture Structure
Aluminum structure + Molded plastic shell, 2 handles,
pan and tilt lock for the convenience of
transportation and maintenance

Movement Parameters
Angle: Pan 540°, Tilt 270°
Maximum Speed: Pan3.52 sec (360°),Tilt 2.50sec (270
°)
Resolution: Pan=2.11°, Pan Fine=0.008°, Tilt=1.05°
,Tilt Fine=0.004°
With electro-optic reset system, pan and tilt can
automatically reposition after accidental movement
 Electronic Control Technology
Built-in self-rechargeable battery
Reset controlling via manual or console
Lamp on/off through remote control
Switching controlling modes
Switching Pan/Tilt speed mode
Light off or CMY closes, power will automatically
decrease
Electronic sensor
Input signal protection
DMX control monitor
Lighting information inquiry
Motor zero 16bit control

Power Supplies
AC200-240V 50/60Hz

Input Power
1450W, Power Factor PFC≥0.98

Safety Protection
Protection of over current, over voltage, over
heating

Working Position
Horizontal or vertical

Standard Certificate
GB7000.1-2007, GB7000.217-2008 and GB17625.1-2003
standard

Dimension
475×468×765mm

Weight
32 kg (E)/ 42 kg (M )
GUANGZHOU CAIYI LIGHT CO.,LTD
http://en.fineart-light.com/
marketing@fineart-light.com
stage lighting manufacture
https://twitter.com/fineartlight
https://plus.google.com/u/0/?tab=wX
https://www.youtube.com/watch?v=1JLq_NVhK-4
https://www.facebook.com/FineArtLight
Main products:
Console Series, DPU Series, Auxiliary Control Equipment,Moving Head Series, Follow Spot Series, Outdoor Light Series,Multi-Media Digital Light,LED Screen,Interface, System Tools
led moving head, stage lighting, moving head, moving head spot, moving head beam, moving head lighings, lighting console, light on stage, moving head wash

FINE 1500w WASH led moving head light

FINE 1500 WASH is a professional wash moving head .It is equipped with a 1500W double end short arc discharge lamp.  Linear and smooth CMY color mixing, CTO color temperature correction. 2 color wheels with 12 color filters, option of linear and uniform soft light expander, independent dimmer and fast strobe.

• 1500W double end short arc discharge lamp
• CMY color mixing system + linear CTO (6500K-2800K)
• 2 fixed color wheels with 12 color filters
• 1 soft light expander, beam angle option: standard (11°-44°), other PC lens(9°-35°)， astigmatic  lens(85°-105°)
• Independent 0-100% dimmer + fast strobe (1-13 times/sec)
• Pan 540°, Tilt 270°, 8bit or 16bit resolution
• Manu display: LCD, option of Chinese and English
• High-quality electronic hardware and mature user-friendly software control system make the fixture   steady and reliable
• Modular structure, easy, fast and convenient for maintenance
Lamp Source
1500W double end short arc discharge lamp
Lamp type: OSRAM HTI 1500W/D7/60或PHILIP MSR GOLDTM 1510 SA/DE
Lamp Cap: SFc10-4
Color temperature: 6000K
Luminous: 165000lm
Average life: 750 hours

Optical System
Imported European Microcrystalline trellis cold glass reflector, 3 groups of high definition lenses
Beam angle linear electronic zoom, option:  standard (11°-44°), PC lens(9°-35°),astigmatic lens(85°-105°)

Color System
2 fixed color wheel with 12 colors+ open white, CMY color mixing system, CTO color linear adjustment

Effects Configuration
Independent dimmer and strobe device, 0-100% linear dimmer, strobe speed: 1-13 times/sec,  macro function

Control and Programming
Control channels: 3 controlling modes , 18（(standard)/ 20（16Bit）/25 (extended)
DMX Protocol: DMX 512, ART-NET, wireless DMX
Manu display: LCD, option of Chinese and English
Resolution control: Pan, Tilt
DMX signal connection: 3 pin and 5 pin XLR input/output

Fixture Structure
Aluminum structure + Molded plastic shell, 2 handles, pan and tilt lock for the convenience of transportation and maintenance

Movement Parameters
Angle: Pan 540°, Tilt 270°
Maximum Speed: Pan3.52 sec (360°),Tilt 2.50sec (270°)
Resolution: Pan=2.11°, Pan Fine=0.008°, Tilt=1.05°,Tilt Fine=0.004°
With electro-optic reset system, pan and tilt can automatically reposition after accidental movement
Electronic Control Technology
Built-in self-rechargeable battery
Reset controlling via manual or console
Lamp on/off through remote control
Switching controlling modes
Switching Pan/Tilt speed mode
Light off or CMY closes, power will automatically decrease
Electronic sensor
Input signal protection
DMX control monitor
Lighting information inquiry
Motor zero 16bit control

Power Supplies
AC200-240V 50/60Hz

Input Power
1890W, Power Factor PFC≥0.98

Safety Protection
Protection of over current, over voltage, over heating

Working Position
Horizontal or vertical

Standard Certificate
GB7000.1-2007, GB7000.217-2008 and GB17625.1-2003 standard

Dimension
475×468×765mm

Weight
32 kg (E)

http://en.fineart-light.com/ --- The famous stage lighting manufacture in China, we can offer you a competitive price with the high quality products, we have our brand ---FINE ART.

Founded in 2002 and located in Guangzhou Civilian Scien-tech industrial zone, Guangzhou Chai Yi Light CO., Ltd, with an area of over 2000 square meters, is a high-tech enterprise integrating with R&D, production, sales and service for the stage lighting products.
With advanced technology, excellent quality, stable performance and high quality service, Fine Art's products have obtained European CE standard and ISO9001. Fine Art has won many honors, such as Guangzhou famous trademark, Guangdong Independent Innovation Product, Double software (including Software copyright registration, Software testing, Software Product Certification, Software Enterprise Certification) certification enterprises, high-tech enterprise certification, Members Council of China Entertainment Technology Association, members of contract first credit" units,the Contract and Promise Keeping Unit, Prozac private in Baiyun District,etc.
At the same time, Fine Art’s lighting products are widely recognized in the market. For example, in 2008, Fine Art participated in the opening and closing ceremonies of Olympic Games on behalf of national brand. Fine Art could also be found in the large-scale music and dance epic "Revival Road" held at the Great Hall of People during the 60th anniversary organized by the Central Propaganda Department. What’s more, Fine Art has been participated in many other large-scales activities such as Zhang Yimou’s version “Turandot”, the Opening and Closing ceremony of the 11th National Games, Guangdong Province Tourism Festival, the Opening and Closing ceremony of Shanghai Expo, the Opening and Closing ceremony of 2010 Asian Games, National Day Ceremony of Turkmenistan, Independent Day Celebration of Israel. Fine Art’s excellent quality is highly praised by all walks of life, making it the 1st choice for all the theaters and large-scale performance. GUANGZHOU CAIYI LIGHT CO.,LTD
http://en.fineart-light.com/
marketing@fineart-light.com
stage lighting manufacture
https://twitter.com/fineartlight
https://plus.google.com/u/0/?tab=wX
https://www.youtube.com/watch?v=1JLq_NVhK-4
https://www.facebook.com/FineArtLight
Main products:
Console Series, DPU Series, Auxiliary Control
Equipment,Moving Head Series, Follow Spot Series,
Outdoor Light Series,Multi-Media Digital Light,LED
Screen,Interface, System Tools
led moving head, stage lighting, moving head, moving
head spot, moving head beam, moving head lighings,
lighting console, light on stage, moving head wash

For the introduction for our factory: https://youtu.be/vpZCnI8zODY

sharpy moving head Platinum 5R 300w

◆ Light Source
Mode: PHILIPS MSD Platinum 15R
Power Rate: 300W
Color temperature:8000K
Luminous Flux：13500lm
Average Life Span: 2000h

◆ Effect Configuration
14 colors
17 gobos
8 facet prism with rotating and moving effect
Beam angle 0-4°
Mechanical+electronic dimmer
High speed strobe 1-13/sec
Pan 540°，8 or 16 bit resolution
Pan 270°，8 or 16 bit resolution
Pan/tilt is driven by 3-phase motor and fast inspected and located
Through encoder,moving quickly and steady
High-powered electronic hardware application,anti-interference
Performance enhanced,steady and reliable
◆ Control and Programming
Control channel: 16 (standard)/20(16 bit)/24(extension)
3 kinds of control channel modes
Protocol: Standard DMX512 protocol
Menu display: 16 million pixels LCD display, Chinese and English can be arbitrary switched,available to display 180°reversely.
DMX signal connection: 3-Pin or 5-Pin XLR input/output
◆ Electronic Control Technology
Self-rechargeable buffer battery
Fixture reset is controlled by menu or light console
Support Ethernet
Remotely control the lamp on/off
The power is automatically decreased when the light or CMY is closed
Fan Intelligent control
Electronic sensor detection
DMX channel level monitoring
Fixture information search
Motor zero 16bit regulation and control
RDM signal bi-direction transmission
Edit menu without electricity

◆Power
AC100-240V 50/60Hz

EXO's Concert in Xi'an Supported by Fine Art LED STAGE LIGHTING

Exo, a famous team in Korea, hold their concert,“EXO FROM. EXOPLANET #1 - THE LOST PLANET - in XI'AN” ,on Aug 2nd, 2014, which is part of their world touring. Over 10,000 fans gathered and screamed at the concert for EXO’s stylish music and dynamic dancing. Fine Art’s lighting impacted the fans by its sharp and shinning light.

EXO have been performing in Seoul, HK, Taiwan, Shanghai, and many other cities since May. Singapore will be the next stop where EXO will bring a storm again.

wonderful stage lighting

Hot sale! 1500w led moving head light for ? dollar

GUANGZHOU CAIYI LIGHT CO.,LTD
http://en.fineart-light.com/
marketing@fineart-light.com
stage lighting manufacture
https://twitter.com/fineartlight
https://plus.google.com/u/0/?tab=wX
https://www.youtube.com/watch?v=1JLq_NVhK-4
https://www.facebook.com/FineArtLight

FINE II-1500 WASH SL  is a moving head which can produce multiple effects under the function of soft light and electronic strobe. This product has not only all the features of soft lighting fixtures but also the strong stroboscopic effect of arc discharge light fixtures. The product will provide a strong light-operated visual effect for the large-scale performance, and produce very impressive blind-eyes effect on the spot.

Optical System

Soft light part

Lamp source: Osram 1500w fastfit single end lamp

Reflector: Oval cold light film reflector

Overall Output of Luminous Flux: 42428lm

Lighting Effect: 22lm/W

Strobe light part

2 pulse xenon lamps, half circular and arc shape (1500w for each lamp)

Lamp life span: 500h

Arc-shaped mirror reflector

Each pulse xenon lamp can work separately or work together

0-100% light intensity control, producing very impressive blind eyes effect

Frequency 0-16Hz

Automatically safety temperature control protection

Effect Equipment

CMY color mixing + CTO color temperature correction

2 color wheels, each wheel has 6 colors

Electronic Zoom: 7.5 °-67 °

Soft light diffusion (7.5 ° 13 °- linear change to 67°)

Light control: Shutter + Strobe

Control and Programming

Control channel: 25(standard)/31(16Bit)/36 (extension) control channel mode

DMX protocol: Standard DMX512 protocol, Art-net light control protocol and wireless DMX512 control

Menu display: 16 million pixels LCD display, random switch of Chinese and English, available to display 180°reversely.

Movement Parameters

Angle: Pan 540°，Tilt 270°

Precision: Pan=2.11°Pan Fine =0.008°Tilt=1.05°Tilt Fine=0.004°

With electro-optic reset system, pan and tilt can automatically reposition after accidental movement.

Electronic Control Technology

• Built-in self-rechargeable buffer battery
• Reset controlling via manual or console
• Ethernet available
• Lamp on/off through remote control
• Lamp off or CMY closes, power will automatically decrease
• Fan Intelligent control
• Electronic sensor
• DMX control monitor
• Fixture information inquiry
• Motor zero 16bit control
• Bi-direction transmission for RDM data
• Menu editing available when power off

◆Power Supply

AC200-240V 50/60Hz

Dimension: 461mm×386mm×826mm

Weight：56.2KG

Channel (16 Bit)

01 Strobe Light 1 Brightness

02 Strobe Light 2 Brightness

03 Strobe Light 1 Continue

04 Strobe Light 2 Continue

05 Strobe Light 1 Speed

06 Strobe Light 2 Speed

07 Strobe Light Power

08 Macro Function

09 Cyan

10 Magenta

11 Yellow

12 CTC

13 Color Wheel 1

14 Color Wheel 2

15 Macro Function for Color

16Strobe

17 Dimmer

18 Dimmer Fine

19 Beam Forming

20 Beam Forming Rotation

21 Zoom In/Out

22 Pan

23 Pan Fine

24 Tilt

25 Tilt Fine

26 Function

27 Reset Channel

28  Lamp Control

29 Pan Time

30 Color Time

31  Focus, Zoom In/Out Time

FINE ART OPENS THE 2014 YOUTH OLYMPIC GAMES CEREMONY IN NANJING, CHINA

The opening ceremony of the second summer Youth Olympic Games (YOG) was held in Nanjing China on 16 August this year. The Games is the second largest event that China has hosted, with 204 countries and nearly 4000 athletes participating. Fine Art is honored to contribute up to 2000 pieces of its lighting fixtures for the opening ceremony, which was held at the Nanjing Olympic Sports Centre.

Produced by Chen Weiya, who was the Executive Director of the 2008 Beijing Olympic Games, the opening ceremony lasted about 90 minutes and was divided into three chapters to show the main theme of “Share Youth, Create Dream”. In the true spirit of the YOG, the show got off to a lively start and remained that way throughout the extravaganza, which was tailored to appeal to young people and to demonstrate the youthful vitality and spirit of the Games. There were 4,000 performers in total, most whom were young students from Chinese universities.

 The ceremony highlighted the great history of Nanjing and China, its icons and landmarks, including the Purple Mountain Observatory and the Yunjin brocade. Explorer Zheng He’s expeditionary voyages to the west and development of the Silk Road were also showcased, as was the Nanjing 2014 theme song “Dianliang Weilai,”, or “Light Up to Meet the Future,” which was performed by an international selection of singers from China, the Republic of Korea and Russia.

High-tech floor projections and mega sized television virtual techonology together with impressive stage lighting efforts not only helped expand the acting space of the many performers but created strong visual impact for the audience watching at the stadium and from their television screens at home. Fine Art’s 1500 and 2000 light series were used to elevate the overall visual experience of the ceremony, with their cutting and image forming, CMY and CTO functions illuminating the stage with vivid colours.

It was reported that most stage lighting equipment for the 2008 Beiijng Olympic Games was made up of European brands, but Chinese brands were used for this year’s YOG. This is positive indication of the rising quality of Chinese lighting products and is truly a milestone for the stage lighting industry in China. It is also worthy of note that Fine Art was the largest stage lighting supplier for this ceremony, owing to the excellent performance of its products.

A list of fixtures used during the ceremony included,

FINE 1500 BEAM

FINE 1500 PERF

FINE 1500 SPOT HPE

FINE 2000 WASH

FINE 2000 PERF

GUANGZHOU CAIYI LIGHT CO.,LTD
http://en.fineart-light.com/
marketing@fineart-light.com
stage lighting manufacture
https://twitter.com/fineartlight
https://plus.google.com/u/0/?tab=wX
https://www.youtube.com/watch?v=1JLq_NVhK-4
https://www.facebook.com/FineArtLight

Fine Art led moving head Lights up Fung Wong's Concert in Birds Nest

On Aug 2nd, Fung Wong’s 2014 Concert in Beijing was held in Bird’s Nest. The 100,000-seat national stadium was completely occupied, refreshing the record among the mainland artists.   Since June, Fung Wong’s touring concert has been held in many cities where Fine Art always the stage lighting supplier that creating an amazing stage with its fixtures FINE 330 BEAM、FINE 2000 WASH、and FINE 1500 SPOT for each station.
The stage was designed by the renowned designer LeRoy who once designed for LadyGaga, Beyonce and many other singers. All the equipments were debugged to match the large stage which was expanded to 10 standard basketball size. Thousands of lighting and special effects videos were set in the lighting controllers, helping to build a rock n roll atmosphere. In 3 hours, Fung Wong sang almost 30 classic songs. Music and the audience’s screams could be even heard a far distance from the bird’s nest.
After this concert, Fung Wong would go to Hang Zhou city to continue his next concert on Sep 30th.

GUANGZHOU CAIYI LIGHT CO.,LTD
http://en.fineart-light.com/
marketing@fineart-light.com
stage lighting manufacture
https://twitter.com/fineartlight
https://plus.google.com/u/0/?tab=wX
https://www.youtube.com/watch?v=1JLq_NVhK-4
https://www.facebook.com/FineArtLight

Fine Art's 1000 Units Fixtures led moving head Illuminate Nanning International Folk Song Arts Festival moving head light

Guangzhou Cai Yi Light Co., Ltd.
Console Series, DPU Series, Auxiliary Control Equipment,Moving Head Series, Follow Spot Series, Outdoor Light Series,Multi-Media Digital Light,LED Screen,Interface, System Tools

http://en.fineart-light.com/
marketing@fineart-light.com
stage lighting manufacture

Even though the Typhoon Kalmaegi happened, Nanning International Folk Song Arts Festival was held as schedule in Guangxi Sports Center on 16th Sep., 2014. There were nearly 1000 units Fine Art’s fixtures were used in this festival performance. This Festival provided wonderful live folk songs as well as touching folk stories that showed by large screen. It created a colorful folk feast for the audience through creative lighting, top sound effect and micro film ways. Basing on the local ethnic customs, this festival highlighted ASEAN characteristics with international features.
All the stage moving heads were provided by Fine Art while the amazing lighting effect was designed by Yang Hao , Liu Yang and Da Xiong from a famous lighting design team.  Fine Art’s console TEKMAND III, flagship product Fine III-2000E SPOT, FINE II-1500 WASH, FINE 1500E WASH and FINE 2500 WASH made a memorable night for the whole world.

350 units FINEART Fixtures moving head lighting Shine at China Golden Eagle TV Art Festival

The 27th China TV Golden Eagle Awards Ceremony, hosted by China Federation of Literary and Art Circles, China TV Artists Association and People’s Government of Hunan Province, was successfully celebrated in Changsha City, Hunan Province on 12th Oct., 2014.  Totally 350 units of FINEART Fixtures were used in this ceremony, including FINE 2500 WASH、120 units FINE 1500 SPOT、192 units FINE XTREME-280 and Follow Spot FINE 2000XF etc. Golden Eagle Festival, short for China Golden Eagle TV Art Festival, is the only national TV Arts Awards ceremony based on the viewers’ vote for TV programs. The 1^st Festival was taken place in Changsha on 19^th Oct., 2000. And now it has become one of the most influential TV programs ceremonies in China. Its reputation in the world is increasing year by year.

Guangzhou Cai Yi Light Co., Ltd.
Console Series, DPU Series, Auxiliary Control Equipment,Moving Head Series, Follow Spot Series, Outdoor Light Series,Multi-Media Digital Light,LED Screen,Interface, System Tools

http://en.fineart-light.com/
marketing@fineart-light.com
stage lighting manufacture

FINEART LIGHTING FOR 22nd APEC WELCOME BANQUET IN BEIJING CHINA

A welcome banquet was held for the 22nd Asia-Pacific Economic Cooperation (APEC) Economic leaders’ meeting in Beijing, China on 10th Nov., 2014. Fine Art, a Chinese stage lighting manufacturer, provided more than 2,000 pieces of lighting equipments for this grand banquet. Bearing the theme of “Shaping the Future through Asia-Pacific Partnership”, this was the second time China has hosted the APEC meeting.
On that evening, breathtaking fireworks combined with spectacular lighting effects lit up the night sky at Beijing’s Olympic Park. Sha Xiaolan, a well-known lighting designer from China, was the chief designer and was tasked with creating a grand visual spectacle of lights and fireworks, wowing the large number of people that gathered around the venue to watch.
This event marks another milestone for Fine Art, as it is another important event that lighting manufacturer has been involved in since the 2014 Youth Olympic Games in Nanjing. Fine Art has developed high-powered and environmentally friendly lighting products since establishment, thus filling a gap in the domestic lighting industry. By the virtue of advanced technology, excellent quality, stable performance as well as great service, Fine Art has surely received high recognition at home and abroad.

Products were used in this banquet as blow,

Model	Qty.
FINE 2500WASH	600
FINE II-1500E BEAM	286
FINE 2000 WASH-PERF	34
FINE 2000 WASH	148
FINE 1500 PERF	184
FINE 1500 SPOT	384
FINE II-1500E WASH	162
LED lighting	384

                 GUANGZHOU CAIYI LIGHT CO.,LTD

Founded in 2002 and located in Guangzhou Civilian Scien-tech industrial zone, Guangzhou Chai Yi Light CO., Ltd, with an area of over 2000 square meters, is a high-tech enterprise integrating with R&D, production, sales and service for the stage lighting products.

With advanced technology, excellent quality, stable performance and high quality service, Fine Art's products have obtained European CE standard and ISO9001. Fine Art has won many honors, such as Guangzhou famous trademark, Guangdong Independent Innovation Product, Double software (including Software copyright registration, Software testing, Software Product Certification, Software Enterprise Certification) certification enterprises, high-tech enterprise certification, Members Council of China Entertainment Technology Association, members of contract first credit" units,the Contract and Promise Keeping Unit, Prozac private in Baiyun District,etc.

At the same time, Fine Art’s lighting products are widely recognized in the market. For example, in 2008, Fine Art participated in the opening and closing ceremonies of Olympic Games on behalf of national brand. Fine Art could also be found in the large-scale music and dance epic "Revival Road" held at the Great Hall of People during the 60th anniversary organized by the Central Propaganda Department. What’s more, Fine Art has been participated in many other large-scales activities such as Zhang Yimou’s version “Turandot”, the Opening and Closing ceremony of the 11th National Games, Guangdong Province Tourism Festival, the Opening and Closing ceremony of Shanghai Expo, the Opening and Closing ceremony of 2010 Asian Games, National Day Ceremony of Turkmenistan, Independent Day Celebration of Israel. Fine Art’s excellent quality is highly praised by all walks of life, making it the 1st choice for all the theaters and large-scale performance.

for the further information, pls browse our website: http://en.fineart-light.com/

marketing@fineart-light.com

https://twitter.com/fineartlight

https://www.youtube.com/watch?v=1JLq_NVhK-4

https://www.facebook.com/pages/Guangzhou-Caiyi-LIGHT-COLTD-FINE-ART
